Model | Daily Treatment Capacity | Total System Working Volume | Aerobic Working Volume | Clarifier Working Volume | Treatment Certification | Documents |
|---|---|---|---|---|---|---|
AP-500 | 500 Gallons | 807 Gallons | 614 Gallons | 193 Gallons | NSF 40 | Engineering Package Prints |
LP-500 | 500 Gallons | 840 Gallons | 662 Gallons | 178 Gallons | NSF 40 | Engineering Package Prints |
AP-600 | 600 Gallons | 978 Gallons | 754 Gallons | 224 Gallons | NSF 40 | Engineering Package Prints |
AP-750 | 750 Gallons | 1,137 Gallons | 916 Gallons | 221 Gallons | NSF 40 | Engineering Package Prints |
AP-1000 | 1,000 Gallons | 1,571 Gallons | 1,169 Gallons | 402 Gallons | NSF 40 | Engineering Package Prints |
AP-1500 | 1,500 Gallons | 1,964 Gallons | 1,381 Gallons | 583 Gallons | NSF 40 | Engineering Package Prints |
Model | Daily Treatment Capacity | Total System Working Volume | Primary Treatment Tank | Aerobic Working Volume | Clarifier Working Volume | Treatment Certification | Documents |
|---|---|---|---|---|---|---|---|
AN-400 | 440 Gallons | 1,197 Gallons | 390 Gallons | 614 Gallons | 193 Gallons | NSF 245 | Engineering Package Prints |
LPAN-40 | 450 Gallons | 1,424 Gallons | 584 Gallons | 662 Gallons | 178 Gallons | NSF 245 | Engineering Package Prints |
AN-500 | 550 Gallons | 1,505 Gallons | 527 Gallons | 754 Gallons | 224 Gallons | NSF 245 | Engineering Package Prints |
LPAN-500 | 550 Gallons | 1,505 Gallons | 527 Gallons | 754 Gallons | 224 Gallons | NSF 245 | Engineering Package Prints |
AN-600 | 660 Gallons | 1,905 Gallons | 768 Gallons | 916 Gallons | 221 Gallons | NSF 245 | Engineering Package Prints |
AN-800 | 800 Gallons | 2,362 Gallons | 835 Gallons | 1,169 Gallons | 402 Gallons | NSF 245 | Engineering Package Prints |
AN-1100 | 1,100 Gallons | 3,101 Gallons | 1,137 Gallons | 1,381 Gallons | 583 Gallons | NSF 245 | Engineering Package Prints |
Title | Model | Files |
|---|---|---|
500 GPD OFFLOT #1 | AP-500/+5 PRE NPDES | |
AP-500/5+3 NPDES | ||
AP-500/5+85 NPDES | ||
AP-500/85+5 NPDES | ||
AP-500/85+85 NPDES | ||
AP-500/1000+3 NPDES | ||
LOW PRO OFFLOT #10 | LP-500/+5 PRE NPDES | |
LP-500/5+3 NPDES | ||
600 GPD OFFLOT #3 | AP-600/+5 PRE NPDES | |
AP-600/+85 PRE NPDES | ||
AP-600/85+5 NPDES | ||
750 GPD OFFLOT #5 | AP-750/+85 PRE_NPDES | |
AP-750/85+5 NPDES | ||
AP-750/85+85 NPDES | ||
AP-750/1000+1000 NPDES | ||
1000 GPD OFFLOT #7 | AP-1000/1000+1000 | |
1500 GPD OFFLOT | AP-1500/1200+1000 NPDES |
Model | Max Flow (lpm) | Recommended Operating Pressure/Vac (kPa) | Power Consumption. (Watts) | Noise Level (dBA @ 1m.) | Weight (kg) | Documents |
|---|---|---|---|---|---|---|
HP-40 | 80 | 20 | 38 | 32 | 5.7 | |
HP-60 | 100 | 25 | 51 | 35 | 7 | |
HP-80 | 120 | 25 | 75 | 36 | 7 | |
HP-100 | 110 | 25 | 100 | 38 | 8.5 | |
HP-100 LL | 130 | 30 | 75 | 42 | 9 | |
HP-120 | 150 | 25 | 125 | 40 | 8.5 | |
HP-120 LL | 150 | 30 | 100 | 45 | 9 | |
HP-150 | 200 | 30 | 155 | 47 | 9 | |
HP-200 | 240 | 30 | 250 | 48 | 9 |
Description | This OPS® provides total control of the aerobic unit including air pump and alarms. Other features include separate disconnect switch (which cuts off power to all electrical components) with an optional lockout feature. It requires a single circuit 120 volt / 20 amp feed. |
Typical Applications Include | Direct Discharge Gravity Flow to Gravel Drain Fields Gravity Flow to Leaching Chambers or any disposal method where a pump is not required. |
Equipment Included | 1 – Air Pump 1 – Polyethylene OPS ® Base & Enclosure 1 – Electrical Control Panel |
Small Components Include | Wiring harnesses, electrical connectors, liquid tight compression fittings, air tubing, shraeder valve, audible alarm, visual alarm, and various other components which provide for integration of the OPS®. |
Light Commercial OPS® Unit (OPS Only) | EC50-11-L-120 OPS® HIBLOW LINEAR FOR AP1000 GRAVITY APPLICATIONS EC50-11-L-200 OPS® HIBLOW LINEAR FOR AP1500 GRAVITY APPLICATIONS |
Residential OPS Unit (OPS Only) | EC50-11-L-80 OPS® HIBLOW LINEAR FOR AP500 GRAVITY APPLICATIONS EC50-11-L-100 OPS® HIBLOW LINEAR FOR AP600 GRAVITY APPLICATIONS EC50-11-L-120 OPS® HIBLOW LINEAR FOR AP750 GRAVITY APPLICATIONS |
Description | This OPS® provides total control of the aerobic unit and pump tank including air pump, water pump and alarms. Other features include two-branch circuit breakers, separate disconnect switch (which cuts off power to all electrical components) with an optional lockout feature. It requires a single circuit 120 volt / 30 amp feed. |
Typical Applications Include | Spray Irrigation Pumping to Gravel Drain Fields Pumping to Low Pressure Dosing Systems Pumping to Leaching Chambers or any disposal method requiring a pump where timed dosing is not required. |
Equipment Included | 1 – Air Pump 1 – Polyethylene OPS ® Base & Enclosure 1 – Electrical Control Panel |
Floats Switches Required | 1 – Water Pump On/Off Float 1 – Pump Tank High Level Alarm Float |
Small Components Include | Wiring harnesses, electrical connectors, liquid tight compression fittings, air tubing, shraeder valve, audible alarm, visual alarm, and various other components which provide for integration of the OPS®. |
Light Commercial OPS® Unit (OPS Only) | EC50-20-L-120 OPS® HIBLOW LINEAR FOR AP1000 FOR PUMP ON DEMAND APPLICATIONS EC50-20-L-200 OPS® HIBLOW LINEAR FOR AP1500 PUMP ON DEMAND APPLICATIONS |
Residential OPS Unit (OPS Only) | EC50-20-L-80 OPS® HIBLOW LINEAR FOR AP500 PUMP ON DEMAND APPLICATIONS EC50-20-L-80-MI OPS® HIBLOW LINEAR FOR AP500 PUMP ON DEMAND MI APPLICATIONS EC50-20-L-100 OPS® HIBLOW LINEAR FOR AP600 PUMP ON DEMAND APPLICATIONS EC50-20-L-100-MI OPS® HIBLOW LINEAR FOR AP600 PUMP ON DEMAND MI APPLICATIONS |
Description | This OPS® provides total control of the aerobic unit and pump tank including air pump, water pump and alarms. Other features include two-branch circuit breakers, separate disconnect switch (which cuts off power to all electrical components) with an optional lockout feature and a 24 hr. timer. It requires a single circuit 120 volt / 30 amp feed. |
Typical Applications Include | Spray Irrigation Pumping to Gravel Drain Fields Pumping to Low Pressure Dosing Systems Pumping to Leaching Chambers or any disposal method requiring a pump where 24 hr. – 15 minute increment timed dosing is required. |
Equipment Included | 1 – Air Pump 1 – Polyethylene OPS ® Base & Enclosure 1 – Electrical Control w/ 24 hr. – 15 min. Timer |
Floats Switches Required | 1 – Water Pump On/Off Float 1 – Pump Tank High Level Alarm Float |
Optional Float Switch | 1 – Pump Tank Timer Override Float |
Small Components Include | Wiring harnesses, electrical connectors, liquid tight compression fittings, air tubing, shraeder valve, audible alarm, visual alarm, and various other components which provide for integration of the OPS®. |
Light Commercial OPS® Unit (OPS Only) | EC50-30-L-120 OPS® HIBLOW LINEAR FOR AP1000 24HR. TIMER APPLICATIONS EC50-30-L-200 OPS® HIBLOW LINEAR FOR AP1500 24HR. TIMER APPLICATIONS |
Residential OPS Unit (OPS Only) | EC50-30-L-80 OPS® HIBLOW LINEAR FOR AP500 NIGHT SPRAY APPLICATIONS EC50-30-L-100 OPS® HIBLOW LINEAR FOR AP600 NIGHT SPRAY APPLICATIONS EC50-30-L-120 OPS® HIBLOW LINEAR FOR AP750 NIGHT SPRAY APPLICATIONS |
Description | This OPS® provides total control of the aerobic unit and pump tank including air pump, water pump and alarms. Other features include high-level override, two-branch circuit breakers, separate disconnect switch (which cuts off power to all electrical components) with an optional lockout feature with a fully adjustable repeat cycle (micro-dosing) timer. It requires a single circuit 120 volt / 30 amp feed. |
Typical Applications Include | Drip Irrigation Pumping to Gravel Drain Fields Pumping to Low Pressure Dosing Systems Pumping to Leaching Chambers or any disposal method requiring a pump where micro-dosing is desired with single float high level override / high level alarm. |
Equipment Included | 1 – Air Pump 1 – Polyethylene OPS ® Base & Enclosure 1 – Electrical Control w/ Micro-dosing Timer |
Floats Switches Required | 1 – Water Pump On/Off Float 1 – Pump Tank High Level Alarm Float/Timer Override Float |
Small Components Include | Wiring harnesses, electrical connectors, liquid tight compression fittings, air tubing, shraeder valve, audible alarm, visual alarm, and various other components which provide for integration of the OPS®. |
Light Commercial OPS® Unit (OPS Only) | EC50-32-L-120 OPS® HIBLOW LINEAR FOR AP1000 TURTLE DRIP APPLICATIONS EC50-32-L-200 OPS® HIBLOW LINEAR FOR AP1500 TURTLE DRIP APPLICATIONS EC50-32-L-80 OPS® HIBLOW LINEAR FOR AP500 TURTLE DRIP APPLICATIONS EC50-32-L-100 OPS® HIBLOW LINEAR FOR AP600 TURTLE DRIP APPLICATIONS EC50-32-L-120 OPS® HIBLOW LINEAR FOR AP750 TURTLE DRIP APPLICATIONS |
Description | The AN Series utilizes both the 5011 (Gravity Discharge) and the 5020 (Pump Discharge), depending on the system. However, the AN Series uses an [additional or special?] specific control panel (120105) to link these systems to the AN Series. Schemeatics to make sure the control panel can be referenced below. |
Part Numbers | 120105 120105 Variations (TBD) |
Schematics | AN Control Panel Schematics and Programming |
Description | The LIV system disinfects the effluent by exposing it to a powerful ultraviolet light in a confined space. A flowrestrictor ensures that the effluent is exposed to the UV light for a sufficient period of time to complete thedisinfection process. A control panel is provided that supplies power to the UV system and has an audible and visible alarm that activates if the bulb fails or the UV current drops below a minimum level. The control panel is housed in a weather proof enclosure and has separate circuit breakers for the UV system and the alarm system. |
Specification Drawings | |
Test Data | Final – UV Disinfection Ohio |
Manual | UV Disenfector O & M |
